| Onderdeel nommer | G150XTN03.6 |
| Handelsmerk | AUO |
| Grootte | 15.0 |
| Toepassing | Industrial |
| Resolusie | 1024×768 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K/16.2M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| vervaardiger | AUO |
| skerm grootte | 15.0 inch |
| pixel nommer | 1024(RGB)×768 (XGA) 85PPI |
| aktiewe area (mm) | 304.128 × 228.096 (H×V) |
| ring area (mm) | 313.55 × 237.25 (H×V) |
| helderheid | 250 cd/m² (Typ.) |
| kykhoek | 45/45/20/40 (Typ.)(CR≥10) |
| goeie uitsig by | - |
| kleurdiepte | 262K/16.2M 60% NTSC |
| massa | 1.10Kgs (Max.) |
| herlaaitempo | 60Hz |
| sein tipe | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 65 °C |
| model naam | G150XTN03.6 |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 326.5 × 253.5 × 10 (H×V×D) |
| behandeling | Antiglare, Hard coating (3H) |
| kontras verhouding | 500 : 1 (Typ.) (TM) |
| reaksie | 5.7/2.3 (Typ.)(Tr/Td) ms |
| werksmodus | TN, Normally White, Transmissive |
| agterlig | WLED , 50K hours , With LED Driver |
| gebruik vir | Industrial |
| raakskerm | Without |
| G150X1-L01 | Innolux | 15.0 | 1024×768 |
| G150XG03 V0 | AUO | 15.0 | 1024×768 |
| G150XG03 V4 | AUO | 15.0 | 1024×768 |
| G150XG03 V5 | AUO | 15.0 | 1024×768 |
| G150XTN02.0 | AUO | 15.0 | 1024×768 |
| G150XTN03.2 | AUO | 15.0 | 1024×768 |
| G150XTN05.0 | AUO | 15.0 | 1024×768 |
| G150XTN06.2 | AUO | 15.0 | 1024×768 |
| G150XTN06.4 | AUO | 15.0 | 1024×768 |
| G150XVN01.0 | AUO | 15.0 | 1024×768 |
