| Onderdeel nommer | G150XAN01.2 |
| Handelsmerk | AUO |
| Grootte | 15.0 |
| Toepassing | Industrial |
| Resolusie | 1024×768 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.2M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| vervaardiger | AUO |
| model naam | G150XAN01.2 |
| skerm grootte | 15.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1024(RGB)×768 (XGA) 85PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 304.128 × 228.096 (H×V) |
| buitelyn (mm) | 326.5 × 253.5 × 6.8 (H×V×D) |
| ring area (mm) | 309.9 × 236.3 (H×V) |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 500 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | AHVA, Normally Black, Transmissive |
| kleurdiepte | 16.2M 60% NTSC |
| agterlig | WLED , 50K hours , With LED Driver |
| massa | 660g (Max.) |
| gebruik vir | Industrial |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (1 ch, 8-bit) , Connector 30 pins |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 70 °C |
