| Onderdeel nommer | G150XAN01.0 |
| Handelsmerk | AUO |
| Grootte | 15.0 |
| Toepassing | Industrial |
| Resolusie | 1024×768 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.2M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | AUO |
| paneel model | G150XAN01.0 |
| paneel grootte | 15.0" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 1024(RGB)×768, XGA, 85PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 304.128(W)×228.096(H) mm |
| ring opening | 309.9(W)×236.3(H) mm |
| omtrek grootte | 326.5(W)×253.5(H) ×9(D) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 350 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| vertoonmodus | AHVA, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kleure vertoon | 16.2M 60% NTSC |
| tipe lamp | WLED , 50K hours , With LED Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | 920g (Max.) |
| aansoek | Industrial |
| sein koppelvlak | LVDS (1 ch, 8-bit) , 20 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 70 °C |
