| Onderdeel nommer | G104STN01.4 |
| Handelsmerk | AUO |
| Grootte | 10.4 |
| Toepassing | Industrial |
| Resolusie | 800×600 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 700:1 |
| Kleure | 262K/16.2M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | AUO |
| model | G104STN01.4 |
| diagonale grootte | 10.4 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 800(RGB)×600 [SVGA] 96PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 211.2(H)×158.4(V) mm |
| buitelyn dof. | - |
| helderheid | - |
| kontras verhouding | 700:1 (Typ.) (TM) |
| kyk rigting | - |
| reaksie tyd | - |
| kykhoek | 80/80/60/70 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 262K/16.2M |
| Ligbron | WLED |
| gewig | - |
| ontwerp vir | Industrial |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | LVDS (1 ch, 6/8-bit) |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
| G104S1-L01 | Innolux | 10.4 | 800×600 |
| G104SN02 V0 | AUO | 10.4 | 800×600 |
| G104SN02 V1 | AUO | 10.4 | 800×600 |
| G104SN02 V2 | AUO | 10.4 | 800×600 |
| G104SN03 V0 | AUO | 10.4 | 800×600 |
| G104SN03 V1 | AUO | 10.4 | 800×600 |
| G104SN03 V4 | AUO | 10.4 | 800×600 |
| G104SN03 V5 | AUO | 10.4 | 800×600 |
| G104SN05 V0 | AUO | 10.4 | 800×600 |
| G104STN01.0 | AUO | 10.4 | 800×600 |
