| Onderdeel nommer | G101STN01.7 |
| Handelsmerk | AUO |
| Grootte | 10.1 |
| Toepassing | Industrial |
| Resolusie | 1024×600 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K/16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | AUO |
| diagonale grootte | 10.1 inch |
| pixel formaat | 1024(RGB)×600 [WSVGA] 117PPI |
| aktiewe area | 222.72(H)×125.28(V) mm |
| helderheid | - |
| kyk rigting | - |
| kykhoek | 70/70/60/60 (Typ.)(CR≥10) |
| ondersteun kleur | 262K/16.7M 45% NTSC |
| gewig | - |
| raamkoers | - |
| omgewing | Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| model | G101STN01.7 |
| tipe | a-Si TFT-LCD , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | - |
| kontras verhouding | 500:1 (Typ.) (TM) |
| reaksie tyd | - |
| bedryfsmodus | TN, Normally White, Transmissive |
| Ligbron | WLED |
| ontwerp vir | Industrial |
| raakpaneel | Without |
