| Onderdeel nommer | G101EAN01.0 |
| Handelsmerk | AUO |
| Grootte | 10.1 |
| Toepassing | Industrial |
| Resolusie | 800×1280 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| vervaardiger | AUO |
| skerm grootte | 10.1 inch |
| pixel nommer | 800(RGB)×1280 (WXGA) 150PPI |
| aktiewe area (mm) | 135.36 × 216.576 (H×V) |
| ring area (mm) | - |
| helderheid | 350 (Typ.)(cd/m²) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 16.7M 60% NTSC |
| massa | 161g (Max.) |
| herlaaitempo | 60Hz |
| model naam | G101EAN01.0 |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 150.3 × 232.43 × 4.8 (H×V×D) |
| behandeling | Antiglare, Antireflection |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| werksmodus | AHVA, Normally Black, Transmissive |
| reaksie | 30 (Typ.)(Tr+Td) ms |
| agterlig | WLED , 15K hours , No Driver |
| gebruik vir | Industrial |
| raakskerm | Without |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| B101UAT02.1 | AUO | 10.1 | 1920×1200 |
| BP101WX1-206 | BOE | 10.1 | 1280×800 |
| BT101IW01 V.0 | Innolux | 10.1 | 1024×600 |
| CLAA101NB03A | CPT | 10.1 | 1024×600 |
| CLAA101WA01 | CPT | 10.1 | 1366×768 |
| G101EVN01.0 | AUO | 10.1 | 1280×800 |
| G101EVN01.3 | AUO | 10.1 | 1280×800 |
| LTN101NT05-T01 | Samsung | 10.1 | 1024×600 |
| LTN101NT05-U03 | Samsung | 10.1 | 1024×600 |
