| Onderdeel nommer | G070VAN01.1 |
| Handelsmerk | AUO |
| Grootte | 7.0 |
| Toepassing | Industrial |
| Resolusie | 800×480 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1300:1 |
| Kleure | 262K/16.7M |
| Agterlig | 7S2P |
| Koppelvlak | LVDS |
| vervaardiger | AUO |
| skerm grootte | 7.0 inch |
| pixel nommer | 800×480(RGB) (WVGA) 133PPI |
| aktiewe area (mm) | 152.4 × 91.44 (H×V) |
| ring area (mm) | 154.2 × 93.24 (H×V) |
| helderheid | 200 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 262K/16.7M 60% NTSC |
| massa | 160g (Typ.) |
| herlaaitempo | 60Hz |
| sein tipe | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| model naam | G070VAN01.1 |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Horizontal Stripe |
| buitelyn (mm) | 166.6 × 107 × 10 (H×V×D) |
| behandeling | Antiglare |
| kontras verhouding | 1300 : 1 (Typ.) (TM) |
| reaksie | 11/19 (Max.)(Tr/Td) ms |
| werksmodus | AHVA, Normally Black, Transmissive |
| agterlig | 7S2P WLED , 30K hours , No Driver |
| gebruik vir | Industrial |
| raakskerm | Without |
| G070VTN01.0 | AUO | 7.0 | 800×480 |
| G070VTT01.0 | AUO | 7.0 | 800×480 |
| G070VVN01.0 | AUO | 7.0 | 800×480 |
| G070VVN01.1 | AUO | 7.0 | 800×480 |
| G070VW01 V0 | AUO | 7.0 | 800×480 |
| G070VW01 V1 | AUO | 7.0 | 800×480 |
| HE070IA-04M | Innolux | 7.0 | 800×1280 |
| N070ICN-GB1 | Innolux | 7.0 | 800×1280 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
| TX18D40VM1CAA | KOE | 7.0 | 800×480 |
