| Onderdeel nommer | G070VAN01.0 |
| Handelsmerk | AUO |
| Grootte | 7.0 |
| Toepassing | Industrial |
| Resolusie | 800×480 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1300:1 |
| Kleure | 262K/16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | AUO |
| model | G070VAN01.0 |
| diagonale grootte | 7.0 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 800×480(RGB) [WVGA] 133PPI |
| konfigurasie | RGB Horizontal Stripe |
| aktiewe area | 152.4(H)×91.44(V) mm |
| buitelyn dof. | 166.6(H)×107(V) ×10(D) mm |
| ring area | 154.2(H)×93.24(V) mm |
| behandeling | Antiglare |
| helderheid | 480 cd/m² (Typ.) |
| kontras verhouding | 1300:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 11/19 (Max.)(Tr/Td) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| bedryfsmodus | AHVA, Normally Black, Transmissive |
| ondersteun kleur | 262K/16.7M 70% NTSC |
| Ligbron | WLED [7S2P] , 50K hours , W/O Driver |
| gewig | 175±10%g |
| ontwerp vir | Industrial |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
