| Onderdeel nommer | FG050020DNCWBG01 |
| Handelsmerk | Data Image |
| Grootte | 5.0 |
| Toepassing | Industrial |
| Resolusie | 320×234 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 350:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | |
| paneel handelsmerk | Data Image |
| paneel grootte | 5.0" |
| resolusie | 320(RGB)×234, 79PPI |
| vertoon area | 102.72(W)×74.53(H) mm |
| omtrek grootte | 126.6(W)×92.4(H) mm |
| helderheid | 350 cd/m² (Typ.) |
| kykhoek | 60/60/40/60 (Typ.)(CR≥10) |
| beste uitsig op | - |
| kleure vertoon | 262K |
| frekwensie | 60Hz |
| gewig | 168g (Typ.) |
| paneel model | FG050020DNCWBG01 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 107(W)×78.9(H) mm |
| oppervlak | Antiglare |
| kontras verhouding | 350:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 5/25 (Typ.)(Tr/Td) |
| tipe lamp | WLED , 20K hours , Without Driver |
| raakskerm | Without |
| aansoek | Industrial |
| A050FW03 V2 | AUO | 5.0 | 480×272 |
| A050VVN01.0 | AUO | 5.0 | 480×800 |
| BTL507212-W677L | BOE | 5.0 | 720×1280 |
| BTL507212-W746L | BOE | 5.0 | 720×1280 |
| CLAN050LL31 1XG | CPT | 5.0 | 480×800 |
| EJ050NA-01D | Innolux | 5.0 | 800×480 |
| LH500WF3-SH01 | LG Display | 5.0 | 1080×1920 |
| PA050XS1 | E Ink | 5.0 | 320×234 |
| TM050NDH01 | Tianma | 5.0 | 480×272 |
| YX050800480WTIPS | 5.0 | 800×480 |
