| Onderdeel nommer | F101NWN7 R0 |
| Handelsmerk | IVO |
| Grootte | 10.1 |
| Toepassing | Pad & Tablet |
| Resolusie | 1920×1200 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 800:1 |
| Kleure | 60% |
| Agterlig | No |
| Koppelvlak | |
| paneel handelsmerk | IVO |
| paneel model | F101NWN7 R0 |
| paneel grootte | 10.1" |
| paneel tipe | a-Si TFT-LCD, CELL |
| resolusie | 1920(RGB)×1200, WUXGA, 224PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 217.44(W)×135.9(H) mm |
| ring opening | - |
| omtrek grootte | 225.5(W)×144.4(H) ×0.4(D) mm |
| oppervlak | - |
| helderheid | 0 cd/m² |
| kontras verhouding | 800:1 (Typ.) (TM) |
| kykhoek | 88/88/88/88 (Typ.)(CR≥10) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 65/45 (Max.)(Tr/Td) |
| glas diepte | 0.20+0.20 mm |
| deurlaatbaarheid | 3.8% (Typ.)(with Polarizer) |
| kleure vertoon | 60% NTSC |
| tipe lamp | No B/L |
| frekwensie | - |
| raakskerm | Without |
| paneel gewig | 56.1g (Max.) |
| aansoek | Pad & Tablet |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| A101SW02 V1 | AUO | 10.1 | 1024×600 |
| B101UAN07.0 | AUO | 10.1 | 1200×1920 |
| F101NWN7-0 | IVO | 10.1 | 1920×1200 |
| G101AGE-L01 | Innolux | 10.1 | 800×600 |
| HJ101IA-01F | Innolux | 10.1 | 1280×800 |
| HSD101PFW2-B01 | HannStar | 10.1 | 1024×600 |
| LP101WH4-SLAB | LG Display | 10.1 | 1366×768 |
| LTN101NT05-T01 | Samsung | 10.1 | 1024×600 |
| M101NWN8 R0 | IVO | 10.1 | 1366×768 |
| N101L6-L0A | Innolux | 10.1 | 1024×600 |
