| Onderdeel nommer | EV190E0M-N50 |
| Handelsmerk | BOE |
| Grootte | 19.0 |
| Toepassing | Medical Imaging |
| Resolusie | 1280×1024 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1200:1 |
| Kleure | Grayscale |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | BOE |
| paneel model | EV190E0M-N50 |
| paneel grootte | 19.0" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 1280(LCR)×1024, SXGA, 86PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 374.784(W)×299.827(H) mm |
| ring opening | 378.8(W)×303(H) mm |
| omtrek grootte | 396(W)×324(H) ×10.4(D) mm |
| oppervlak | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 1300 cd/m² (Typ.) |
| kontras verhouding | 1200:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| vertoonmodus | ADS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 14 (Typ.)(G to G) |
| kleure vertoon | Grayscale |
| tipe lamp | WLED , 50K hours , Without Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | 1.69Kgs (Typ.) |
| aansoek | Medical Imaging |
| sein koppelvlak | LVDS (2 ch, 8-bit) , 30 pins Connector |
| insetspanning | 5.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
