| Onderdeel nommer | EV121WXM-N12 |
| Handelsmerk | BOE |
| Grootte | 12.1 |
| Toepassing | Medical Imaging |
| Resolusie | 1280×800 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1200:1 |
| Kleure | 262K/16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | BOE |
| model | EV121WXM-N12 |
| diagonale grootte | 12.1 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1280(RGB)×800 [WXGA] 124PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 261.12(H)×163.2(V) mm |
| buitelyn dof. | 277.7(H)×180.6(V) ×9.2(D) mm |
| ring area | 264.12(H)×166.2(V) mm |
| behandeling | Antiglare (Haze 25%) |
| helderheid | 500 cd/m² (Typ.) |
| kontras verhouding | 1200:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedryfsmodus | ADS, Normally Black, Transmissive |
| ondersteun kleur | 262K/16.7M 100% sRGB |
| Ligbron | WLED [12S4P] , 50K hours , With LED Driver |
| gewig | TBD |
| ontwerp vir | Medical Imaging |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
