| Onderdeel nommer | ET104S0M-N11 |
| Handelsmerk | BOE |
| Grootte | 10.4 |
| Toepassing | Industrial |
| Resolusie | 800×600 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 262K/16.2M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | BOE |
| diagonale grootte | 10.4 inch |
| pixel formaat | 800(RGB)×600 [SVGA] 96PPI |
| aktiewe area | 211.2(H)×158.4(V) mm |
| ring area | 215(H)×162(V) mm |
| helderheid | 350 cd/m² (Typ.) |
| kyk rigting | 12 o'clock |
| kykhoek | 80/80/65/75 (Typ.)(CR≥10) |
| ondersteun kleur | 262K/16.2M 55% NTSC |
| gewig | 288g (Typ.) |
| raamkoers | 60Hz |
| koppelvlak tipe | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | ET104S0M-N11 |
| tipe | a-Si TFT-LCD , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 236(H)×176.9(V) ×5.9(D) mm |
| behandeling | Antiglare (Haze 25%) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| bedryfsmodus | TN, Normally White, Transmissive |
| Ligbron | WLED , 30K hours , W/O Driver |
| ontwerp vir | Industrial |
| raakpaneel | Without |
