| Onderdeel nommer | ES050YMM-A00 |
| Handelsmerk | BOE |
| Grootte | 5.0 |
| Toepassing | Round Display Instru |
| Resolusie | 1080×1080 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1300:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| vervaardiger | BOE |
| model naam | ES050YMM-A00 |
| skerm grootte | 5.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1080(RGB)×1080 215PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 127.008 × 127.008 (H×V) |
| buitelyn (mm) | 143 × 140 × 4.45 (H×V×D) |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 1300 : 1 (Typ.) (TM) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| reaksie | 40 (Max.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | ADS, Normally Black, Transmissive |
| kleurdiepte | 16.7M 80% NTSC |
| agterlig | WLED , No Driver |
| massa | - |
| gebruik vir | Round Display Instruments & Meters Home Appliance |
| herlaaitempo | 60Hz |
| raakskerm | PCAP |
| Storage Temp.: -30 ~ 75 °C Operating Temp.: -20 ~ 60 °C |
