| Onderdeel nommer | E295FCA62.A |
| Handelsmerk | EDO |
| Grootte | 3.0 |
| Toepassing | HMD VR AR |
| Resolusie | 1080×1200 |
| Samestelling | AM-OLED, OLED |
| Helderheid | |
| CR | 10000:1 |
| Kleure | 16.7M |
| Agterlig | self |
| Koppelvlak | MIPI |
| handelsmerk | EDO |
| model | E295FCA62.A |
| diagonale grootte | 3.0 inch |
| tipe | AM-OLED, OLED |
| pixel formaat | 1080(RGB)×1200 446PPI |
| konfigurasie | Sub-Pixel Rendering |
| aktiewe area | 50.11(H)×55.68(V) mm |
| buitelyn dof. | 52.91(H)×62.58(V) ×0.75(D) mm |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 10000:1 (Min.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 2 (Typ.)(Tr+Tf) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥200) |
| bedryfsmodus | - |
| ondersteun kleur | 16.7M 109% NTSC |
| Ligbron | self |
| gewig | 4.80±0.40g |
| ontwerp vir | HMD VR AR |
| raamkoers | 60Hz |
| raakpaneel | Without |
| d-ic detail | COG Built-in RM67295 |
| koppelvlak tipe | MIPI (4 data lanes) , 39 pins FPC |
| kragtoevoer | 1.8/3.3/6.4/4.6/-2.5V (Typ.)(VDDI/VCI/VSP/ELVDD/ELVSS) |
| omgewing | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -55 ~ 125 °C |
| A030DN05 V0 | AUO | 3.0 | 320×240 |
| A030DW01 V1 | AUO | 3.0 | 320×240 |
| AL2004A | Other | 3.0 | 20×4 |
| C-51505NFJ-SLG-AHN | Kyocera | 3.0 | 20×2 |
| COM30T3N64ZLG | ORTUSTECH | 3.0 | 320×240 |
| DMC-20261NYJ-LY-CDE-CKN | Kyocera | 3.0 | 20×2 |
| DX08D11VM0AAA | KOE | 3.0 | 480×800 |
| EQ030AS181 | PDI | 3.0 | 320×240 |
| LH300WQ1-ED01 | LG Display | 3.0 | 240×400 |
| TD030MHEB3 | TPO | 3.0 | 320×240 |
