| Onderdeel nommer | DV438FBD-N50 |
| Handelsmerk | BOE |
| Grootte | 43.8 |
| Toepassing | Digital Signage Stre |
| Resolusie | 3840×1080 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 1.07B |
| Agterlig | No |
| Koppelvlak | V-by-One |
| paneel handelsmerk | BOE |
| paneel model | DV438FBD-N50 |
| paneel grootte | 43.8" (Native bar) |
| paneel tipe | a-Si TFT-LCD, CELL |
| resolusie | 3840(RGB)×1080, 91PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 1071.36(W)×301.32(H) mm |
| ring opening | - |
| omtrek grootte | 1084(W)×314.88(H) ×1.35(D) mm |
| oppervlak | Antiglare (Haze 25%) |
| helderheid | 0 cd/m² |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| vertoonmodus | ADS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 14 (Typ.)(G to G) |
| glas diepte | 0.50+0.50 mm |
| deurlaatbaarheid | 4.2% (Typ.)(with Polarizer) |
| kleure vertoon | 1.07B |
| tipe lamp | No B/L |
| frekwensie | 60Hz |
| raakskerm | Without |
| bestuurder ic | COF Built-in 12 source chips |
| paneel gewig | 900g (Typ.) |
| aansoek | Digital Signage Stretched Bar LCD |
| sein koppelvlak | V-by-One 8 lane , 51 pins Connector |
| insetspanning | 12.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
