| Onderdeel nommer | DV430FHM-NN1 |
| Handelsmerk | BOE |
| Grootte | 43 |
| Toepassing | Digital Signage |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1200:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | BOE |
| model | DV430FHM-NN1 |
| diagonale grootte | 43 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1920(RGB)×1080 [FHD] 51PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 940.896(H)×529.254(V) mm |
| buitelyn dof. | 961.7(H)×550.1(V) ×27.7(D) mm |
| ring area | - |
| behandeling | Antiglare (Haze 1%), Hard coating (3H) |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 1200:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 8 (Typ.)(G to G) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| bedryfsmodus | ADS, Normally Black, Transmissive |
| ondersteun kleur | 16.7M 72% NTSC |
| Ligbron | WLED , 30K hours , With LED Driver |
| gewig | 8.36Kgs (Typ.) |
| ontwerp vir | Digital Signage |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | LVDS (2 ch, 8-bit) , 51 pins Connector |
| kragtoevoer | 12.0V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
