| Onderdeel nommer | DV190E0M-N11 |
| Handelsmerk | BOE |
| Grootte | 19.0 |
| Toepassing | Digital Signage |
| Resolusie | 1280×1024 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 2 |
| Koppelvlak | LVDS |
| vervaardiger | BOE |
| model naam | DV190E0M-N11 |
| skerm grootte | 19.0 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 1280(RGB)×1024 (SXGA) 86PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 374.784 × 299.827 (H×V) |
| buitelyn (mm) | 396 × 324 × 10.4 (H×V×D) |
| ring area (mm) | 376.78 × 303.0 (H×V) |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 250 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 14 (Typ.)(G to G) ms |
| goeie uitsig by | Symmetry |
| werksmodus | HADS, Normally Black, Transmissive |
| kleurdiepte | 16.7M 72% NTSC |
| agterlig | 2 strings WLED , 30K hours , No Driver |
| massa | 1.52Kgs |
| gebruik vir | Digital Signage |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (2 ch, 8-bit) , 30 pins Connector |
| spanningstoevoer | 5.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
