| Onderdeel nommer | DMF-50174 |
| Handelsmerk | OPTREX |
| Grootte | 5.7 |
| Toepassing | Industrial |
| Resolusie | 320×240 |
| Samestelling | STN-LCD, LCM |
| Helderheid | |
| CR | |
| Kleure | Monochrome |
| Agterlig | CCFL |
| Koppelvlak | Parallel |
| handelsmerk | OPTREX |
| model | DMF-50174 |
| diagonale grootte | 5.7 inch |
| tipe | STN-LCD, LCM |
| pixel formaat | 320×240 [QVGA] 70PPI |
| konfigurasie | Rectangle |
| aktiewe area | 115.17(H)×86.37(V) mm |
| buitelyn dof. | 174(H)×112(V) ×14(D) mm |
| ring area | 122.0(H)×92.0(V) mm |
| behandeling | - |
| kyk rigting | - |
| reaksie tyd | - |
| kykhoek | - |
| bedryfsmodus | STN |
| ondersteun kleur | Monochrome |
| Ligbron | CCFL , W/O Driver |
| gewig | - |
| ontwerp vir | Industrial |
| raamkoers | 70Hz |
| raakpaneel | Without |
| koppelvlak tipe | Parallel Data (1ch, 4-bit) , 14 pins Connector |
| kragtoevoer | 5.0V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
