| Onderdeel nommer | DLC0430LZG |
| Handelsmerk | Other |
| Grootte | 4.3 |
| Toepassing | PND |
| Resolusie | 480×272 |
| Samestelling | LCM |
| Helderheid | 650 |
| CR | 500:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | TTL |
| paneel handelsmerk | DLC |
| paneel model | DLC0430LZG 1 Compatible model |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 4.3 inch |
| resolusie | 480(RGB)×272 , WQVGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 95.04×53.856 mm |
| buitelyn | 105.5×67.2×3.1 mm |
| oppervlak | |
| helderheid | 650 cd/m² (Typ.) |
| kontras verhouding | 500:1 (Typ.) |
| kleure vertoon | 16.7M (6-bit + Hi-FRC), CIE193150% |
| reaksie tyd | 20 (Typ.)(Tr+Td) |
| kykhoek | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 5S2PWLEDWithout Driver |
| sein koppelvlak | Parallel RGB (1 ch, 8-bit), 40 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | PND |
