| Onderdeel nommer | DBT070CTV50R9 |
| Handelsmerk | No Brand |
| Grootte | 7.0 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 800×480 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | No Brand |
| diagonale grootte | 7.0 inch |
| pixel formaat | 800(RGB)×480 [WVGA] 134PPI |
| aktiewe area | 154.08(H)×85.92(V) mm |
| ring area | 157(H)×89.5(V) mm |
| helderheid | 1000 cd/m² (Typ.) |
| kyk rigting | - |
| kykhoek | 70/70/50/70 (Typ.)(CR≥10) |
| ondersteun kleur | 16.7M |
| gewig | TBD |
| raamkoers | 60Hz |
| model | DBT070CTV50R9 |
| tipe | a-Si TFT-LCD , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 165(H)×100(V) mm |
| behandeling | Antiglare |
| kontras verhouding | 500:1 (Typ.) (TM) |
| reaksie tyd | 10/15 (Typ.)(Tr/Td) |
| bedryfsmodus | TN, Normally White, Transmissive |
| Ligbron | WLED , 20K hours , W/O Driver |
| ontwerp vir | Industrial Outdoor High Brightness |
| raakpaneel | Without |
| AT070TN83 | Innolux | 7.0 | 800×480 |
| AT070TN83 V.1 | Innolux | 7.0 | 800×480 |
| AT070TN94 | Innolux | 7.0 | 800×480 |
| C070VW02 V1 | AUO | 7.0 | 800×480 |
| G070VVN01.0 | AUO | 7.0 | 800×480 |
| LMS700KF07 | Samsung | 7.0 | 800×480 |
| LQ070T1LG01 | SHARP | 7.0 | 800×480 |
| LQ070Y5DG30 | SHARP | 7.0 | 800×480 |
| PM070WL3 | E Ink | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
