| Onderdeel nommer | CT024TN02 V.6 |
| Handelsmerk | Innolux |
| Grootte | 2.4 |
| Toepassing | Mobile Phone |
| Resolusie | 240×320 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 300:1 |
| Kleure | 65K |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | Innolux |
| model | CT024TN02 V.6 |
| diagonale grootte | 2.4 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 240(RGB)×320 [QVGA] 166PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 36.72(H)×48.96(V) mm |
| buitelyn dof. | - |
| helderheid | - |
| kontras verhouding | 300:1 (Typ.) (TM) |
| kyk rigting | 12 o'clock |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kykhoek | 45/45/50/20 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 65K 60% NTSC |
| Ligbron | WLED |
| gewig | - |
| ontwerp vir | Mobile Phone |
| raamkoers | - |
| raakpaneel | 4-wire Resistive Touch |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
