| Onderdeel nommer | CLAP101ND06 CW |
| Handelsmerk | CPT |
| Grootte | 10.1 |
| Toepassing | Netbook PC Digital P |
| Resolusie | 1024×600 |
| Samestelling | a-Si TFT-LCD , CELL |
| Helderheid | |
| CR | 600:1 |
| Kleure | 262K/16.2M |
| Agterlig | No |
| Koppelvlak | |
| paneel handelsmerk | CPT |
| paneel grootte | 10.1" |
| resolusie | 1024(RGB)×600, WSVGA, 117PPI |
| vertoon area | 222.72(W)×125.28(H) mm |
| omtrek grootte | 230(W)×134.3(H) ×1.43(D) mm |
| helderheid | 0 cd/m² |
| kykhoek | 70/70/70/50 (Typ.)(CR≥10) |
| beste uitsig op | - |
| glas diepte | 0.50+0.50 mm |
| kleure vertoon | 262K/16.2M 53% NTSC |
| frekwensie | 60Hz |
| vorm styl | - |
| paneel model | CLAP101ND06 CW |
| paneel tipe | a-Si TFT-LCD , CELL |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Antiglare |
| kontras verhouding | 600:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| deurlaatbaarheid | 5.6% (Typ.)(with Polarizer) |
| tipe lamp | No B/L |
| raakskerm | Without |
| aansoek | Netbook PC Digital Photo Frame Portable DVD Player |
