| Onderdeel nommer | CLAA123PA02CW |
| Handelsmerk | CPT |
| Grootte | 12.3 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 1440×540 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 700:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | CPT |
| model | CLAA123PA02CW |
| diagonale grootte | 12.3 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1440(RGB)×540 125PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 291.6(H)×109.35(V) mm |
| buitelyn dof. | 312.9(H)×132.2(V) ×19.2(D) mm |
| ring area | 294.8(H)×112.4(V) mm |
| behandeling | Antiglare (Haze 25%) |
| helderheid | 800 cd/m² (Typ.) |
| kontras verhouding | 700:1 (Typ.) (TM) |
| kyk rigting | 6 o'clock |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kykhoek | 60/60/50/60 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 16.7M 70% NTSC |
| Ligbron | WLED [8S3P] , 30K hours , W/O Driver |
| gewig | 510g (Typ.) |
| ontwerp vir | Industrial Outdoor High Brightness Automotive Display |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | LVDS (1 ch, 8-bit) , 30 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
