| Onderdeel nommer | CLAA101WK07 XN |
| Handelsmerk | CPT |
| Grootte | 10.1 |
| Toepassing | Automotive Display |
| Resolusie | 1280×720 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 900:1 |
| Kleure | 262K/16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | CPT |
| diagonale grootte | 10.1 inch |
| pixel formaat | 1280(RGB)×720 [WXGA] 144PPI |
| aktiewe area | 224.64(H)×126.36(V) mm |
| ring area | 227.64(H)×129.36(V) mm |
| helderheid | 600 cd/m² (Typ.) |
| kyk rigting | Symmetry |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| ondersteun kleur | 262K/16.7M 70% NTSC |
| gewig | 430g (Typ.) |
| raamkoers | 60Hz |
| model | CLAA101WK07 XN |
| tipe | a-Si TFT-LCD , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 238.8(H)×148.05(V) ×8.7(D) mm |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| kontras verhouding | 900:1 (Typ.) (TM) |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| bedryfsmodus | HFFS, Normally Black, Transmissive |
| Ligbron | WLED [6S5P] , 30K hours , W/O Driver |
| ontwerp vir | Automotive Display |
| raakpaneel | Without |
