| Onderdeel nommer | CLAA080WK02 XN |
| Handelsmerk | CPT |
| Grootte | 8.0 |
| Toepassing | Automotive Display |
| Resolusie | 1280×720 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 900:1 |
| Kleure | 262K/16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | CPT |
| model | CLAA080WK02 XN |
| diagonale grootte | 8.0 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1280(RGB)×720 [WXGA] 183PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 177.024(H)×99.576(V) mm |
| buitelyn dof. | 186.5(H)×117.22(V) ×13.1(D) mm |
| ring area | 179.03(H)×101.58(V) mm |
| behandeling | Antiglare (Haze 25%) |
| helderheid | 600 cd/m² (Typ.) |
| kontras verhouding | 900:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedryfsmodus | HFFS, Normally Black, Transmissive |
| ondersteun kleur | 262K/16.7M 70% NTSC |
| Ligbron | WLED [5S4P] , 30K hours , W/O Driver |
| gewig | TBD |
| ontwerp vir | Automotive Display |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | LVDS (1 ch, 6/8-bit) , 60 pins FPC |
| kragtoevoer | 3.3/12.4/22/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| omgewing | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
