| Onderdeel nommer | CLAA070LQ02 XN |
| Handelsmerk | CPT |
| Grootte | 7.0 |
| Toepassing | Automotive Display |
| Resolusie | 800×480 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 900:1 |
| Kleure | 262K/16.7M |
| Agterlig | 7S2P |
| Koppelvlak | LVDS |
| vervaardiger | CPT |
| model naam | CLAA070LQ02 XN |
| skerm grootte | 7.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 800(RGB)×480 (WVGA) 133PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 152.4 × 91.44 (H×V) |
| buitelyn (mm) | 165 × 104 × 7.3 (H×V×D) |
| ring area (mm) | 154.4 × 93.44 (H×V) |
| behandeling | Antiglare (Haze 25%) |
| helderheid | 760 cd/m² (Typ.) |
| kontras verhouding | 900 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 25 (Typ.)(Tr+Tf) ms |
| goeie uitsig by | Symmetry |
| werksmodus | HFFS, Normally Black, Transmissive |
| kleurdiepte | 262K/16.7M 70% NTSC |
| agterlig | 7S2P WLED , 30K hours , No Driver |
| massa | 175g (Typ.) |
| gebruik vir | Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (1 ch, 6/8-bit) , FPC 60 pins |
| spanningstoevoer | 3.3/13.0/20.0/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| maks. graderings | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
