| Onderdeel nommer | CC580PV5D |
| Handelsmerk | PANDA |
| Grootte | 58 |
| Toepassing | TV Sets |
| Resolusie | 3840×2160 |
| Samestelling | Oxide TFT-LCD , CELL |
| Helderheid | |
| CR | 6000:1 |
| Kleure | 1.07B |
| Agterlig | No |
| Koppelvlak | |
| handelsmerk | PANDA |
| diagonale grootte | 58 inch |
| pixel formaat | 3840(RGB)×2160 [UHD] 76PPI |
| aktiewe area | 1270.08(H)×721.44(V) mm |
| ring area | - |
| helderheid | 0 cd/m² |
| kyk rigting | Symmetry |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| plaat dikte | 0.50+0.50 mm |
| ondersteun kleur | 1.07B 70% NTSC |
| gewig | 2.84Kgs (Typ.) |
| raamkoers | 60Hz |
| model | CC580PV5D |
| tipe | Oxide TFT-LCD , CELL |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 1282.88(H)×734.44(V) ×1.36(D) mm |
| behandeling | Antiglare, Hard coating (2H) |
| kontras verhouding | 6000:1 (Typ.) (TM) |
| reaksie tyd | 8 (Typ.)(G to G) |
| bedryfsmodus | UV2A, Normally Black, Transmissive |
| oordrag | 5.5% (Typ.)(with Polarizer) |
| Ligbron | No B/L |
| ontwerp vir | TV Sets |
| raakpaneel | Without |
| LK580Z3LA13 | SHARP | 58 | 2560×1080 |
| V580DJ2-QS5 | Innolux | 58 | 3840×2160 |
| V580DK1-QS2 | Innolux | 58 | 3840×2160 |
| V580DK2-KS1 | Innolux | 58 | 3840×2160 |
| V580DK2-KS1 Rev.C8 | Innolux | 58 | 3840×2160 |
| V580HJ1-LD6 | Innolux | 58 | 1920×1080 |
| V580HJ1-LE6 | Innolux | 58 | 1920×1080 |
| V580HK1-LD6 | Innolux | 58 | 1920×1080 |
| V580HK1-LE6 | Innolux | 58 | 1920×1080 |
| V580HK1-LS6 | Innolux | 58 | 1920×1080 |
