| Onderdeel nommer | CC500PV1D |
| Handelsmerk | PANDA |
| Grootte | 50 |
| Toepassing | TV Sets |
| Resolusie | 3840×2160 |
| Samestelling | CELL, Oxide TFT-LC |
| Helderheid | |
| CR | 5000:1 |
| Kleure | 1.07B |
| Agterlig | No |
| Koppelvlak | V-by-One |
| vervaardiger | PANDA |
| model naam | CC500PV1D |
| skerm grootte | 50 inch |
| tipe skerm | CELL, Oxide TFT-LCD |
| pixel nommer | 3840(RGB)×2160 (UHD) 89PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 1095.8 × 616.41 (H×V) |
| buitelyn (mm) | 1106.84 × 628.01 × 1.37 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare, Hard coating (2H) |
| helderheid | 0 cd/m² |
| kontras verhouding | 5000 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 8 (Typ.)(G to G) ms |
| goeie uitsig by | Symmetry |
| werksmodus | UV2A, Normally Black, Transmissive |
| glas dikte | 0.50+0.50 mm |
| deurlaatbaarheid | 5.2% (Typ.)(with Polarizer) |
| kleurdiepte | 1.07B 70% NTSC |
| agterlig | No B/L |
| massa | 2.12Kgs (Typ.) |
| gebruik vir | TV Sets |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| bestuurder ic lys | Built-in COF 12 source chips |
| sein tipe | V-by-One 8 lane , Connector 51 pins |
| spanningstoevoer | 12.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
