| Onderdeel nommer | CC240LV1D |
| Handelsmerk | PANDA |
| Grootte | 23.8 |
| Toepassing | TV Sets |
| Resolusie | 1920×1080 |
| Samestelling | Oxide TFT-LCD , CELL |
| Helderheid | |
| CR | 5000:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | |
| paneel handelsmerk | PANDA |
| paneel grootte | 23.8" |
| resolusie | 1920(RGB)×1080, FHD, 92PPI |
| vertoon area | 527.04(W)×296.46(H) mm |
| omtrek grootte | 534.04(W)×307.76(H) ×1.37(D) mm |
| helderheid | 0 cd/m² |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| glas diepte | 0.50+0.50 mm |
| kleure vertoon | 16.7M 74% NTSC |
| frekwensie | 60Hz |
| gewig | 510g (Typ.) |
| paneel model | CC240LV1D |
| paneel tipe | Oxide TFT-LCD , CELL |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Antiglare, Hard coating (2H) |
| kontras verhouding | 5000:1 (Typ.) (TM) |
| vertoonmodus | UV2A, Normally Black, Transmissive |
| reaksie tyd | 8 (Typ.)(G to G) |
| deurlaatbaarheid | 4.3% (Typ.)(with Polarizer) |
| tipe lamp | No B/L |
| raakskerm | Without |
| aansoek | TV Sets |
