| Onderdeel nommer | C123VAN01.0 |
| Handelsmerk | AUO |
| Grootte | 12.3 |
| Toepassing | Automotive Display |
| Resolusie | 1440×540 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | |
| Kleure | 16.7M |
| Agterlig | - |
| Koppelvlak | RSDS |
| paneel handelsmerk | AUO |
| paneel grootte | 12.3" |
| resolusie | 1440(RGB)×540, 125PPI |
| vertoon area | 291.6(W)×109.35(H) mm |
| omtrek grootte | 308.5(W)×129(H) mm |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M |
| frekwensie | 60Hz |
| paneel gewig | 580±58g |
| sein koppelvlak | RSDS (1 Channel) FPC |
| omgewing | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C |
| paneel model | C123VAN01.0 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 294.8(W)×112.35(H) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| vertoonmodus | AHVA, Normally Black, Transmissive |
| reaksie tyd | - |
| tipe lamp | |
| raakskerm | Without |
| aansoek | Automotive Display |
| AV123Z7M-N11 | BOE | 12.3 | 1920×720 |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
