| Onderdeel nommer | C123HAN02.5 |
| Handelsmerk | AUO |
| Grootte | 12.3 |
| Toepassing | Automotive Display |
| Resolusie | 1920×720 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 8S4P |
| Koppelvlak | |
| vervaardiger | AUO |
| model naam | C123HAN02.5 |
| skerm grootte | 12.3 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1920(RGB)×720 167PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 292.032 × 109.512 (H×V) |
| buitelyn (mm) | 310.75 × 129.86 × 16.23 (H×V×D) |
| ring area (mm) | 293.94 × 111.42 (H×V) |
| behandeling | Antiglare |
| helderheid | 600 cd/m² (Min.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| reaksie | 15/45 (Typ.)(Tr/Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | AHVA, Normally Black, Transmissive |
| kleurdiepte | 16.7M 75% NTSC |
| agterlig | 8S4P WLED , 10K hours , No Driver |
| massa | 570±57g |
| gebruik vir | Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
