| Onderdeel nommer | C101EAN02.0 |
| Handelsmerk | AUO |
| Grootte | 10.1 |
| Toepassing | Outdoor High Brightn |
| Resolusie | 1280×720 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | MIPI |
| handelsmerk | AUO |
| model | C101EAN02.0 |
| diagonale grootte | 10.1 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1280(RGB)×720 [WXGA] 145PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 223.68(H)×125.82(V) mm |
| buitelyn dof. | 238.6(H)×148(V) ×10.8(D) mm |
| ring area | 226.78(H)×132.22(V) mm |
| behandeling | Antiglare |
| helderheid | 780 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 20/20 (Max.)(Tr/Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| bedryfsmodus | AHVA, Normally Black, Transmissive |
| ondersteun kleur | 16.7M 98% sRGB |
| Ligbron | WLED [8S3P] , 10K hours , W/O Driver |
| gewig | 400±40g |
| ontwerp vir | Outdoor High Brightness Automotive Display |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | MIPI (4 data lanes) , 40 pins FPC |
| kragtoevoer | 3.3/3.3V (Typ.)(VDD/VDDA) |
| omgewing | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| B101EW05 V0 | AUO | 10.1 | 1280×800 |
| BP101WX1-100 | BOE | 10.1 | 1280×800 |
| BT101IW01 V.0 | Innolux | 10.1 | 1024×600 |
| LP101WH1-TLA1 | LG Display | 10.1 | 1366×768 |
| LP101WH1-TLB1 | LG Display | 10.1 | 1366×768 |
| LQ101R1SX01A | SHARP | 10.1 | 2560×1600 |
| LTN101AT03-801 | Samsung | 10.1 | 1366×768 |
| N101L6-L0B | Innolux | 10.1 | 1024×600 |
| TV101WUM-NH0 | BOE | 10.1 | 1200×1920 |
| VVX10F011B00 | Panasonic | 10.1 | 1920×1200 |
