| Onderdeel nommer | C101EAN01.1 |
| Handelsmerk | AUO |
| Grootte | 10.1 |
| Toepassing | Automotive Display |
| Resolusie | 1280×720 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| paneel handelsmerk | AUO |
| paneel model | C101EAN01.1 |
| paneel grootte | 10.1" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 1280(RGB)×720, WXGA, 145PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 223.68(W)×125.82(H) mm |
| ring opening | - |
| helderheid | - |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| vertoonmodus | AHVA, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 20/20 (Max.)(Tr/Td) |
| kleure vertoon | 16.7M |
| tipe lamp | WLED |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | - |
| aansoek | Automotive Display |
| omgewing | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
