| Onderdeel nommer | C100HAT01.0 |
| Handelsmerk | AUO |
| Grootte | 10.0 |
| Toepassing | Automotive Display |
| Resolusie | 1560×700 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| vervaardiger | AUO |
| model naam | C100HAT01.0 |
| skerm grootte | 10.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1560(RGB)×700 171PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 231.66 × 103.95 (H×V) |
| buitelyn (mm) | 259.36 × 131.32 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare, Antireflection |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| reaksie | 30 (Max.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | AHVA, Normally Black, Transmissive |
| kleurdiepte | 16.7M |
| agterlig | WLED |
| massa | 375±38g |
| gebruik vir | Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | - |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
