| Onderdeel nommer | C084XAT01.0 |
| Handelsmerk | AUO |
| Grootte | 8.4 |
| Toepassing | Automotive Display |
| Resolusie | 1024×768 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| vervaardiger | AUO |
| model naam | C084XAT01.0 |
| skerm grootte | 8.4 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 1024(RGB)×768 (XGA) 152PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 170.496 × 127.872 (H×V) |
| buitelyn (mm) | 185.5 × 143.9 (H×V×D) |
| ring area (mm) | 176.92 × 134.33 (H×V) |
| behandeling | Antiglare, Antireflection |
| helderheid | - |
| kontras verhouding | 800 : 1 (Typ.) (TM) |
| kykhoek | - |
| reaksie | 30 (Max.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | AHVA, Normally Black, Transmissive |
| kleurdiepte | 16.7M |
| agterlig | WLED |
| massa | 420g±42g |
| gebruik vir | Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | PCAP |
| sein tipe | LVDS (1 ch, 8-bit) , 40 pins Connector |
| maks. graderings | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
