| Onderdeel nommer | C084SAT01.1 |
| Handelsmerk | AUO |
| Grootte | 8.4 |
| Toepassing | Automotive Display |
| Resolusie | 800×600 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| vervaardiger | AUO |
| skerm grootte | 8.4 inch |
| pixel nommer | 800×600(RGB) (SVGA) 118PPI |
| aktiewe area (mm) | 170.88 × 128.16 (H×V) |
| helderheid | - |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 16.7M |
| massa | - |
| herlaaitempo | 60Hz |
| maks. graderings | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 90 °C |
| model naam | C084SAT01.1 |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Horizontal Stripe |
| buitelyn (mm) | - |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| reaksie | 15/20 (Typ.)(Tr/Td) ms |
| werksmodus | AHVA, Normally Black, Transmissive |
| agterlig | WLED , No Driver |
| gebruik vir | Automotive Display |
| raakskerm | Without |
| AA084SB11 | Mitsubishi | 8.4 | 800×600 |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| AA084XA03 | Mitsubishi | 8.4 | 1024×768 |
| G084SN03 V1 | AUO | 8.4 | 800×600 |
| M084GNS1 R1 | IVO | 8.4 | 800×600 |
| NL10276BC16-01 | NLT | 8.4 | 1024×768 |
| NL6448BC26-01 | NLT | 8.4 | 640×480 |
| T-51639D084JU-FW-A-AB | Kyocera | 8.4 | 1024×768 |
| TM084SDHG01 | Tianma | 8.4 | 800×600 |
| TM084SDHG03 | Tianma | 8.4 | 800×600 |
