| Onderdeel nommer | C080VTN04.0 |
| Handelsmerk | AUO |
| Grootte | 8.0 |
| Toepassing | Automotive Display |
| Resolusie | 800×480 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | Parallel |
| handelsmerk | AUO |
| model | C080VTN04.0 |
| diagonale grootte | 8.0 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 800(RGB)×480 [WVGA] 115PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 175.2(H)×105.12(V) mm |
| buitelyn dof. | - |
| ring area | - |
| behandeling | Antiglare |
| kyk rigting | - |
| reaksie tyd | 15/20 (Typ.)(Tr/Td) |
| kykhoek | 60/60/40/60 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 262K |
| Ligbron | WLED |
| gewig | - |
| ontwerp vir | Automotive Display |
| raamkoers | 60Hz |
| raakpaneel | - |
| koppelvlak tipe | Parallel RGB (1 ch, 6-bit) , 60 pins Connector |
| omgewing | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 95 °C |
