| Onderdeel nommer | C042FAN01.8 |
| Handelsmerk | AUO |
| Grootte | 4.2 |
| Toepassing | Outdoor High Brightn |
| Resolusie | 480×272 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 262K |
| Agterlig | 3S2P |
| Koppelvlak | |
| vervaardiger | AUO |
| model naam | C042FAN01.8 |
| skerm grootte | 4.2 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 480(RGB)×272 (WQVGA) 131PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 92.88 × 52.632 (H×V) |
| buitelyn (mm) | 102.8 × 68.52 × 20 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare |
| helderheid | 700 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 80/80/80/80 (Min.)(CR≥10) |
| reaksie | 13/14 (Typ.)(Tr/Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | AHVA, Normally Black, Transmissive |
| kleurdiepte | 262K 71% NTSC |
| agterlig | 3S2P WLED , 10K hours , No Driver |
| massa | 89.8g (Typ.) |
| gebruik vir | Outdoor High Brightness Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
