| Onderdeel nommer | BV055HDM-T00 |
| Handelsmerk | BOE |
| Grootte | 5.5 |
| Toepassing | Mobile Phone |
| Resolusie | 720×1280 |
| Samestelling | Assembly, a-Si TFT |
| Helderheid | |
| CR | 1200:1 |
| Kleure | 16.7M |
| Agterlig | - |
| Koppelvlak | |
| vervaardiger | BOE |
| model naam | BV055HDM-T00 |
| skerm grootte | 5.5 inch |
| tipe skerm | Assembly, a-Si TFT-LCD |
| pixel nommer | 720(RGB)×1280 (WXGA) 268PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 68.04 × 120.96 (H×V) |
| buitelyn (mm) | - |
| helderheid | - |
| kontras verhouding | 1200 : 1 (Typ.) (TM) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| reaksie | 25/25 (Typ.)(Tr/Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | ADS, Normally Black, Transmissive |
| kleurdiepte | 16.7M 70% NTSC |
| agterlig | |
| massa | - |
| gebruik vir | Mobile Phone |
| herlaaitempo | 60Hz |
| raakskerm | On-Cell Touch |
| 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| CLAN055WA41 3XB | CPT | 5.5 | 720×1280 |
| CM546B1-002 | CSOT | 5.5 | 1080×1920 |
| LH550WF4-SJ11 | LG Display | 5.5 | 1080×1920 |
| LQ055T3SX02 | SHARP | 5.5 | 1080×1920 |
| LQ055T3SX04 | SHARP | 5.5 | 1080×1920 |
| LS055R1SX04 | SHARP | 5.5 | 1440×2560 |
| NL3224BC35-20 | NLT | 5.5 | 320×240 |
| NL3224BC35-22 | NLT | 5.5 | 320×240 |
| PW056XU1 | E Ink | 5.5 | 480×234 |
| TM055JVZG02 | Tianma | 5.5 | 720×1280 |
