| Onderdeel nommer | BB050HDG-TC1-6D00 |
| Handelsmerk | BOE |
| Grootte | 5.0 |
| Toepassing | Mobile Phone |
| Resolusie | 720×1280 |
| Samestelling | AM-OLED, OLED |
| Helderheid | |
| CR | 17000:1 |
| Kleure | 16.7M |
| Agterlig | self |
| Koppelvlak | MIPI |
| paneel handelsmerk | BOE |
| paneel model | BB050HDG-TC1-6D00 |
| paneel grootte | 5.0" |
| paneel tipe | AM-OLED, OLED |
| resolusie | 720(RGB)×1280, WXGA, 295PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 61.92(W)×110.08(H) mm |
| ring opening | - |
| omtrek grootte | 64.12(W)×116.72(H) mm |
| oppervlak | Hard coating |
| helderheid | 350 cd/m² (Typ.) |
| kontras verhouding | 17000:1 (Typ.) (TM) |
| kykhoek | 80/80/80/80 (Min.) |
| vertoonmodus | OLED |
| beste uitsig op | Symmetry |
| reaksie tyd | - |
| kleure vertoon | 16.7M 101% NTSC |
| tipe lamp | self , 10K hours |
| frekwensie | 60Hz |
| raakskerm | On-Cell Touch |
| bestuurder ic | COG Built-in RM67120 |
| paneel gewig | TBD |
| aansoek | Mobile Phone |
| sein koppelvlak | MIPI (4 data lanes) |
| insetspanning | 2.8/1.8/6.0/4.6/-3.4V (Typ.)(VCI/VDDIO/AVDD/ELVDD/ELVSS) |
| omgewing | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
