| Onderdeel nommer | B173QTN01.0 |
| Handelsmerk | AUO |
| Grootte | 17.3 |
| Toepassing | Laptop |
| Resolusie | 2560×1440 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 700:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | eDP |
| handelsmerk | AUO |
| model | B173QTN01.0 (AUO1096) |
| diagonale grootte | 17.3 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 2560(RGB)×1440 [Quad-HD] 170PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 382.08(H)×214.92(V) mm |
| buitelyn dof. | 398.1(H)×252.5(V) ×4.3(D) mm |
| ring area | - |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 700:1 (Typ.) (TM) |
| kyk rigting | - |
| reaksie tyd | 5 (Typ.)(Tr+Tf) |
| kykhoek | 70/70/60/60 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 16.7M 72% NTSC |
| Ligbron | WLED , 15K hours , With LED Driver |
| vorm styl | Flat (PCBA Flat, T3.4~4.0mm) |
| ontwerp vir | Laptop |
| raamkoers | 120Hz |
| raakpaneel | Without |
| koppelvlak tipe | eDP (4 Lanes) , eDP1.4 , 40 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
