| Onderdeel nommer | B170PW06 V3 |
| Handelsmerk | AUO |
| Grootte | 17.0 |
| Toepassing | NBPC |
| Resolusie | 1440×900 |
| Samestelling | LCM |
| Helderheid | 220 |
| CR | 400:1 |
| Kleure | 262K |
| Agterlig | CCFL |
| Koppelvlak | LVDS |
| paneel handelsmerk | AUO |
| paneel model | B170PW06 V3 1 Compatible model |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 17.0 inch |
| resolusie | 1440(RGB)×900 , WXGA+ |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 367.2×229.5 mm |
| buitelyn | 382.2×244.5×6.7 mm |
| vorm styl | Wedge (PCBA Bent, Depth ≥5.2mm) |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 220 cd/m² (Typ.) |
| kontras verhouding | 400:1 (Typ.) |
| kleure vertoon | 262K (6-bit), CIE193145% |
| reaksie tyd | 2/6 (Typ.)(Tr/Td) |
| kykhoek | 45/45/25/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 1 pcsCCFLWithout Driver |
| sein koppelvlak | LVDS (2 ch, 6-bit), 30 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | NBPC |
| B170PW01 V1 | AUO | 17.0 | 1440×900 |
| B170PW02 V0 | AUO | 17.0 | 1440×900 |
| B170PW03 V0 | AUO | 17.0 | 1440×900 |
| B170PW03 V1 | AUO | 17.0 | 1440×900 |
| B170PW03 V3 | AUO | 17.0 | 1440×900 |
| B170PW03 V4 | AUO | 17.0 | 1440×900 |
| B170PW03 V5 | AUO | 17.0 | 1440×900 |
| B170PW06 V2 | AUO | 17.0 | 1440×900 |
| B170PW06 V3 | AUO | 17.0 | 1440×900 |
| B170PW07 V0 | AUO | 17.0 | 1440×900 |
| B121EW03 V9 | AUO | 12.1 | 1280×800 |
| B121EW08 V0 | AUO | 12.1 | 1280×800 |
| B141EW04 V7 | AUO | 14.1 | 1280×800 |
| LP121S1 | LG Display | 12.1 | 800×600 |
| LP133WF2-SPA1 | LG Display | 13.3 | 1920×1080 |
| LP133WX2-TLC1 | LG Display | 13.3 | 1280×800 |
| LTD121KX4K | TOSHIBA | 12.1 | 1280×800 |
| LTN140HL02-B01 | Samsung | 14.0 | 1920×1080 |
| N140HGE-EAA | Innolux | 14.0 | 1920×1080 |
| TM121XG-02L10 | SANYO | 12.1 | 1024×768 |
