| Onderdeel nommer | B160HW02 V0 |
| Handelsmerk | AUO |
| Grootte | 16.0 |
| Toepassing | NBPC |
| Resolusie | 1920×1080 |
| Samestelling | LCM |
| Helderheid | 225 |
| CR | 500:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | eDP |
| paneel handelsmerk | AUO |
| paneel model | B160HW02 V0 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 16.0 inch |
| resolusie | 1920(RGB)×1080 , FHD |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 354.24×199.26 mm |
| buitelyn | 375×218 mm |
| oppervlak | Antiglare |
| helderheid | 225 cd/m² (Typ.) |
| kontras verhouding | 500:1 (Typ.) |
| kleure vertoon | 262K (6-bit), CIE193182% |
| reaksie tyd | 4 (Typ.)(Tr+Td) |
| kykhoek | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | WLEDEmbedded (LED Driver) |
| sein koppelvlak | eDP (4 Lanes), 30 pins |
| insetspanning | 3.3/5.0V (Typ.)(VDD33/VDD5) |
| aansoek | NBPC |
