| Onderdeel nommer | B133ZAN01.0 |
| Handelsmerk | AUO |
| Grootte | 13.3 |
| Toepassing | Laptop |
| Resolusie | 3840×2160 |
| Samestelling | LTPS TFT-LCD, LCM |
| Helderheid | |
| CR | 1800:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | eDP |
| handelsmerk | AUO |
| model | B133ZAN01.0 |
| diagonale grootte | 13.3 inch |
| tipe | LTPS TFT-LCD, LCM |
| pixel formaat | 3840(RGB)×2160 [UHD] 332PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 293.76(H)×165.24(V) mm |
| buitelyn dof. | 298.96(H)×176.19(V) ×4.71(D) mm |
| ring area | - |
| behandeling | Glare (Haze 0%) |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 1800:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedryfsmodus | AHVA, Normally Black, Transmissive |
| ondersteun kleur | 16.7M 72% NTSC |
| Ligbron | WLED , With LED Driver |
| vorm styl | Slim (PCBA Bent, T≤3.0mm) |
| ontwerp vir | Laptop |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | eDP (4 Lanes) , eDP1.3 , 40 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
