| Onderdeel nommer | B133HAN05.F |
| Handelsmerk | AUO |
| Grootte | 13.3 |
| Toepassing | Laptop |
| Resolusie | 1920×1080 |
| Samestelling | LTPS TFT-LCD, LCM |
| Helderheid | |
| CR | 1400:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | eDP |
| paneel handelsmerk | AUO |
| paneel model | B133HAN05.F (AUO5F2D) |
| paneel grootte | 13.3" |
| paneel tipe | LTPS TFT-LCD, LCM |
| resolusie | 1920(RGB)×1080, FHD, 166PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 293.76(W)×165.24(H) mm |
| ring opening | - |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 1400:1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| vertoonmodus | AHVA, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 27/35 (Typ./Max.)(Tr+Td) |
| kleure vertoon | 16.7M |
| tipe lamp | WLED , 15K hours , With LED Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| vorm styl | - |
| aansoek | Laptop |
| sein koppelvlak | eDP (2 Lanes) , eDP1.3 , 30 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
