| Onderdeel nommer | B116XTN02.3 HW2G |
| Handelsmerk | AUO |
| Grootte | 11.6 |
| Toepassing | Laptop Netbook PC |
| Resolusie | 1366×768 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 400:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | eDP |
| handelsmerk | AUO |
| diagonale grootte | 11.6 inch |
| pixel formaat | 1366(RGB)×768 [WXGA] 135PPI |
| aktiewe area | 256.125(H)×144(V) mm |
| ring area | - |
| helderheid | 220 cd/m² (Typ.) |
| kyk rigting | 6 o'clock |
| kykhoek | 45/45/15/35 (Typ.)(CR≥10) |
| ondersteun kleur | 262K 45% NTSC |
| vorm styl | Slim (PCBA Flat, T≤3.2mm) |
| raamkoers | 60Hz |
| koppelvlak tipe | eDP (2 Lanes) , 30 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | B116XTN02.3 HW2G |
| tipe | a-Si TFT-LCD , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 278(H)×168(V) ×3(D) mm |
| behandeling | Hard coating (3H) |
| kontras verhouding | 400:1 (Typ.) (TM) |
| reaksie tyd | 8 (Typ.)(Tr+Td) |
| bedryfsmodus | TN, Normally White, Transmissive |
| Ligbron | WLED , 15K hours , With LED Driver |
| ontwerp vir | Laptop Netbook PC |
| raakpaneel | Without |
