| Onderdeel nommer | B080UAB01.0 |
| Handelsmerk | AUO |
| Grootte | 8.0 |
| Toepassing | Pad & Tablet |
| Resolusie | 1200×1920 |
| Samestelling | Assembly , a-Si TF |
| Helderheid | |
| CR | 900:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| vervaardiger | AUO |
| skerm grootte | 8.0 inch |
| pixel nommer | 1200(RGB)×1920 (WUXGA) 283PPI |
| aktiewe area (mm) | 107.64 × 172.224 (H×V) |
| ring area (mm) | - |
| helderheid | 350 (Typ.)(cd/m²) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 16.7M 60% NTSC |
| massa | - |
| herlaaitempo | 60Hz |
| model naam | B080UAB01.0 |
| tipe skerm | Assembly , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 120.6 × 206.6 × 3.45 (H×V×D) |
| behandeling | Hard coating (7H) |
| kontras verhouding | 900 : 1 (Typ.) (TM) |
| werksmodus | - |
| reaksie | 27 (Typ.)(Tr+Tf) ms |
| agterlig | WLED , 15K hours , No Driver |
| gebruik vir | Pad & Tablet |
| raakskerm | On-Cell Touch |
