| Onderdeel nommer | AX080D002F |
| Handelsmerk | KOE |
| Grootte | 31.5 |
| Toepassing | LCTV |
| Resolusie | 1366×768 |
| Samestelling | LCM |
| Helderheid | 450 |
| CR | 850:1 |
| Kleure | 16.7M |
| Agterlig | EEFL |
| Koppelvlak | LVDS |
| paneel handelsmerk | IPS Alpha |
| paneel model | AX080D002F |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 31.5 inch |
| resolusie | 1366(RGB)×768 , WXGA |
| vertoonmodus | IPS-Pro, Normally Black, Transmissive |
| aktiewe area | 697.685×392.256 mm |
| buitelyn | 760×450 mm |
| oppervlak | Antiglare |
| helderheid | 450 cd/m² (Typ.) |
| kontras verhouding | 850:1 (Typ.) |
| kleure vertoon | 16.7M (8-bit) |
| reaksie tyd | 8/6 (Typ.)(Tr/Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 16 pcsEEFLEmbedded (Inverter) |
| sein koppelvlak | LVDS (1 ch, 8-bit), 30 pins |
| insetspanning | 12.0V (Typ.) |
| aansoek | LCTV |
