| Onderdeel nommer | AV035QVE-N10 |
| Handelsmerk | BOE |
| Grootte | 3.5 |
| Toepassing | Handheld & PDA |
| Resolusie | 240×320 |
| Samestelling | CELL , a-Si TFT-LC |
| Helderheid | |
| CR | 900:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | |
| vervaardiger | BOE |
| skerm grootte | 3.5 inch |
| pixel nommer | 240(RGB)×320 (QVGA) 114PPI |
| aktiewe area (mm) | 53.28 × 71.04 (H×V) |
| ring area (mm) | - |
| helderheid | 0 (cd/m²) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| glas dikte | 0.50+0.50 mm |
| kleurdiepte | 16.7M 70% NTSC |
| massa | TBD |
| herlaaitempo | - |
| model naam | AV035QVE-N10 |
| tipe skerm | CELL , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 60.68 × 82.64 × 1 (H×V×D) |
| behandeling | Without Polarizer |
| kontras verhouding | 900 : 1 (Typ.) (TM) |
| werksmodus | ADS, Normally Black, Transmissive |
| reaksie | 35 (Typ.)(Tr+Td) ms |
| deurlaatbaarheid | 3.8% (Typ.)(with Polarizer) |
| agterlig | No B/L |
| gebruik vir | Handheld & PDA |
| raakskerm | Without |
| 35HVF0H | SII | 3.5 | 320×480 |
| A035QN05 V0 | AUO | 3.5 | 320×240 |
| ACX565AKM-7 | SONY | 3.5 | 800×480 |
| COM35H3P09UTC | ORTUSTECH | 3.5 | 480×640 |
| H345VW01 V0 | AUO | 3.5 | 480×800 |
| LMS350GF12-005 | Samsung | 3.5 | 320×240 |
| NL2432HC22-41B | NLT | 3.5 | 240×320 |
| PD035VX8 | E Ink | 3.5 | 480×640 |
| PT035TN23 V.1 | Innolux | 3.5 | 320×240 |
| TM035KDH04 | Tianma | 3.5 | 320×240 |
